HII Pressure Vessel Steel Plate Dimensions to Specify for an Order

Pricing: Request an Order-Specific Quote

Reference: HII boiler and pressure vessel steel. Check grade designation, product form and ordering requirements.

If the standard size steel materials can not meet your demands, We aslo supply HII boiler and pressure vessel steel processing service. you can find one-stop solution for various customized steel processing requirements: Large vessels, structural parts, semi-products, components, manufacturing supporting ...

Processing: Specify drawing requirements with your enquiry.

E-mail: [email protected]

Whatsapp: +86 13569929107

HII boiler and pressure vessel steel Description

HII boiler and pressure vessel steel. Check the complete grade, product form, applicable edition and ordered dimensions.

Confirm the governing construction code, grade and class, design temperature, delivery heat treatment, test requirements and mill certificate.

Supply dimensions, lead time and inspection are confirmed against the order and mill offer.

HII boiler and pressure vessel steel, also named heat-resistant steel, DIN 17155 HII pressure vessel steel is mainly used for the manufacture of hot-rolled steel plates for steam boiler equipment, pressure vessels, large pressure pipes and similar components. HII steel plate implements the DIN 17155 standard. The digital grade is 1.0425. It is mainly used for the manufacture of spherical storage tanks with a size of more than 50 cubic meters. It is widely used in petroleum, chemical, power stations, boilers and other industries. Equipment and components such as boilers, spherical tanks, oil and gas tanks, liquefied gas tanks, boiler drums, liquefied petroleum gas cylinders, high-pressure water pipes of hydropower stations, turbine volutes, etc.

DIN 17155 HII boiler and pressure vessel steel can still show characteristics at higher temperature, local temperature can reach 600C, and can still show characteristics under long-term load conditions. DIN 17155 HII boiler steel not only guarantees normal temperature performance, but also guarantees mechanical properties at higher temperatures, and is suitable for steam boiler equipment, pressure vessels with higher working temperatures and similar structural parts. HII is delivered in a normalized state. As one of the main suppliers of HII pressure vessel steel in China, BBN Steel can provide HII pressure vessel steel plates of various sizes, and provide cutting and deep processing services according to customer needs to meet customer requirements.

HII boiler and pressure vessel steel Datasheet

Legacy technical note · verification required

Width: 1000mm/1219mm/1240mm/1500mm/2000mm or as customer's requirements

Legacy technical note · verification required

Thickness: Cold rolled: 0.1~4.0mm, Hot rolled: 4mm~100mm

Legacy technical note · verification required

Length: 100mm to 12000mm or as customer's request

Delivery condition: Hot rolled, controlled rolled, or normalized

Surface: Black Finish, Oiled, Shot Blasted, Spray Paint, Coated,Galvanized Or as Your Request

Cutting service: Large steel plate cut to flat plate sizes, or cut to any size by drawing

Deep processing: After cutting large plate into the general sizes by drawing, milling and grinding, and make angles, polishing, and make special part

HII boiler and pressure vessel steel Chemical composition

Legacy technical table · verification required

Confirm every value against the applicable edition, thickness and material certificate.

Legacy technical table
DIN 17155 Steel Plates Chemical Composition
Grade C Si Mn Cr Mo Ni Other Other
HII 0.20 0.35 0.50-1.30 0.25 0.10 0.30 Al≥0.02,
Nb≤0.01,
Ti≤0.03,
V≤0.03
P≤0.035
S≤0.030
Cu≤0.30
17Mn4 0.14-0.20 0.40 0.90-1.40 0.25 0.10 0.30
19Mn6 0.15-0.22 0.30-0.60 1.00-1.60 0.25 0.10 0.30
15Mo3 0.12-0.20 0.10-0.35 0.40-0.90 0.25 0.25-0.35 0.30
13CrMo44 0.08-0.18 0.10-0.35 0.40-1.00 0.7-1.1 0.40-0.60
10CrMo9-10 0.06-0.15 0.50 0.40-0.70 2.0-2.5 0.90-1.10

HII boiler and pressure vessel steel Mechanical Properties

Legacy technical table · verification required

Confirm every value against the applicable edition, thickness and material certificate.

Legacy technical table
DIN17155 Steel Plates Tensile Strength (Mpa)
Thickness HII 17Mn4 19Mn6 15Mo3 13CrMo44 10CrMo9-10
360-480 410-530 460-580 510-650 440-590 440-590 480-630
360-480 410-530 450-570 490-630 430-580 430-580 460-630
350-480 400-530 440-570 480-630 420-570 420-570 460-630

Equivalent Grade of HII boiler and pressure vessel steel

Legacy technical table · verification required

Confirm every value against the applicable edition, thickness and material certificate.

Legacy technical table
Grade Standard Country Application
P265GH EN 10028-2 Europen Mainly used in petroleum, chemical, power station, boiler and other industries to make reactors, heat exchangers, separators, spherical tanks.
A516Gr. 60 ASTM USA Mainly used in storage containers and pipelines for various liquid alkenes, natural gas liquefaction plants, large-scale Natural gas.
SG295 JIS Japan Mainly used in storage containers and pipelines for various liquid alkenes, natural gas liquefaction plants, large-scale Natural gas.

Record and evidence status

Source for the page topic: BBN Steel Sales legacy catalogue, record 42475. The exact edition and material evidence for legacy technical values are pending verification.
