16MnDR Pressure Vessel Steel Plate Dimensions to Specify for an Order
Pricing: Request an Order-Specific Quote
Reference: 16MnDR Steel. Check grade designation, product form and ordering requirements.
If the standard size steel materials can not meet your demands, We aslo supply 16MnDR Steel processing service. you can find one-stop solution for various customized steel processing requirements: Large vessels, structural parts, semi-products, components, manufacturing supporting ...
Processing: Specify drawing requirements with your enquiry.
16MnDR Steel Description
16MnDR Steel. Check the complete grade, product form, applicable edition and ordered dimensions.
Confirm the governing construction code, grade and class, design temperature, delivery heat treatment, test requirements and mill certificate.
Supply dimensions, lead time and inspection are confirmed against the order and mill offer.
16MnDR boiler and pressure vessel steel is a kind of low temperature vessel steel plate. 16Mn—indicates that the manganese content in the steel plate is about 0.16%, D-indicates low temperature, and R-indicates pressure vessel. Therefore, 16MnDR is used for steel plates for -40 degree pressure vessels. 16MnDR container steel plate has high-quality properties such as high strength, high toughness, fatigue resistance, impact resistance, corrosion resistance, welding and easy processing, and has been widely used in storage containers and pipelines for various liquid alkenes, natural gas liquefaction plants, large-scale Natural gas, petroleum gas equipment and storage and transportation facilities, liquefied gas tanks, nuclear power reactor pressure vessels, hydrogenation reactors and other parts.
Legacy technical note · verification required
The material 16MnDR pressure vessel steel plate equivalent to ASTM A516 Grade 70, and the phosphorus and sulfur content of 16MnDR vessel steel is lower than that of ordinary steel. In addition to higher tensile strength and elongation requirements than ordinary steel, impact toughness also needs to be guaranteed. 16MnDR steel plate in normalizing state, the minimum service temperature of 6-36mm thickness is -40°, and the minimum service temperature of 36-100mm thickness is -30°. 16MnDR pressure vessel steel is usually delivered in the state of hot rolling, controlled rolling and normalizing. Goods, and can do flaw detection according to customer needs. We can provide GB3531 16MnDR low temperature pressure vessel steel in different sizes, and can provide cutting and deep processing services to meet the needs of different customers.
16MnDR Steel Datasheet
Legacy technical note · verification required
Width: 1000mm/1219mm/1240mm/1500mm/2000mm or as customer's requirements
Legacy technical note · verification required
Thickness: Cold rolled: 0.1~4.0mm, Hot rolled: 4mm~100mm
Legacy technical note · verification required
Length: 100mm to 12000mm or as customer's request
Delivery condition: Hot rolled, controlled rolled, or normalized
Surface: Black Finish, Oiled, Shot Blasted, Spray Paint, Coated,Galvanized Or as Your Request
Cutting service: Large steel plate cut to flat plate sizes, or cut to any size by drawing
Deep processing: After cutting large plate into the general sizes by drawing, milling and grinding, and make angles, polishing, and make special part
16MnDR Steel Chemical composition
Legacy technical table · verification required
Confirm every value against the applicable edition, thickness and material certificate.
| GB3531 Steel Plates Chemical Composition | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| GB3531 | C | Si | Mn | Ni | Mo | Alt | P | S | Other |
| 16MnDR | 0.20 | 0.15-0.50 | 1.2-1.6 | 0.40 | - | ≥0.02 | 0.020 | 0.010 | - |
| 15MnNiDR | 0.18 | 0.15-0.50 | 1.2-1.6 | 0.20-0.6 | - | ≥0.02 | 0.020 | 0.008 | V 0.05 |
| 15MnNiNbDR | 0.18 | 0.15-0.50 | 1.2-1.6 | 0.30-0.7 | - | - | 0.020 | 0.008 | Nb 0.015-0.04 |
| 09MnNiDR | 0.12 | 0.15-0.50 | 1.2-1.6 | 0.30-0.8 | - | ≥0.02 | 0.020 | 0.008 | Nb 0.04 |
| 08Ni3DR | 0.10 | 0.15-0.35 | 0.3-0.8 | 3.25-3.7 | 0.12 | - | 0.015 | 0.005 | V 0.05 |
| 06Ni9DR | 0.08 | 0.15-0.35 | 0.3-0.8 | 8.50-10 | 0.10 | - | 0.008 | 0.004 | V 0.01 |
16MnDR Steel Mechanical Properties
Legacy technical table · verification required
Confirm every value against the applicable edition, thickness and material certificate.
| GB3531 Steel Plate Mechanical Properties | ||||||
|---|---|---|---|---|---|---|
| GB3531 | Thickness | Tensile Strength | Yield | Elongation | Temperature | Impact |
| Grade | mm | Mpa | Strength | min. | ℃ | Energy |
| 16MnDR | 6-16mm | 490-620 | ≥315Mpa | 21% | -40 | 47J |
| 16-36mm | 470-600 | ≥295Mpa | ||||
| 36-60mm | 460-590 | ≥285Mpa | ||||
| 60-100mm | 450-580 | ≥275Mpa | -30 | 47J | ||
| 100-120mm | 440-570 | ≥265Mpa | ||||
| 15MnNiDR | 6-16mm | 490-620 | ≥325Mpa | 20% | -45 | 60J |
| 16-36mm | 480-610 | ≥315Mpa | ||||
| 36-60mm | 470-600 | ≥305Mpa | ||||
| 15MnNiNbDR | 10-16mm | 530-630 | ≥370Mpa | 20% | -50 | 60J |
| 16-36mm | 530-630 | ≥360Mpa | ||||
| 36-60mm | 520-620 | ≥350Mpa | ||||
| 09MnNiDR | 6-16mm | 440-570 | ≥300Mpa | 23% | -70 | 60J |
| 16-36mm | 430-560 | ≥280Mpa | ||||
| 36-60mm | 430-560 | ≥270Mpa | ||||
| 60-120mm | 420-550 | ≥260Mpa | ||||
| 08Ni3DR | 6-60mm | 490-620 | ≥320Mpa | 21% | -100 | 60J |
| 60-100mm | 480-610 | ≥300Mpa | ||||
| 06Ni9DR | 5-30mm | 680-820 | ≥560Mpa | 18% | -196 | 100J |
| 30-50mm | ≥550Mpa | |||||
Equivalent Grade of 16MnDR Steel
Legacy technical table · verification required
Confirm every value against the applicable edition, thickness and material certificate.
| Grade | Standard | Country | Application |
|---|---|---|---|
| A572 Grade 50 | ASTM | USA | Mainly used in construction steel structures, construction machinery, mining and mountainous machinery, trucks, bridges, pressure vessels, etc. |
Record and evidence status
Source for the page topic: BBN Steel Sales legacy catalogue, record 42472. The exact edition and material evidence for legacy technical values are pending verification.
